Bright Stripe LED

Mechanical Specifications

• Size: 39.75” x 2.06” x 3.78”
• Weight: 5lbs
• DMX Connection: 3-pin XLR connectors
• Power Connection: Edison Connection In & Out
• Fastening System: 38mm Treaded mounting points

Electrical Specifications

• LEDQuantity:144
• LEDType:5mm
• Segment Control: 8 segments or 16 segment selectable via display
• LED Lifeetimee: 50,000 to 100,000 hrs
• Power Consumption: 110V-220V 50/60Hz
• Watts:17
• Amps:0.14

Control & Programming

• Protocol: DMX512
• DMXChannels:

  • Mode 1: 3 Channels R, G, B
  • Mode 2: 24 Channels 8X R, G, B
  • Mode 3: 48 Channels 16X R, G, B
  • Mode 4: 6 Channels Dimmer
  • R, G, B, Strobe, Macro
• Operatingmode:DMX,
• Master/Slave,Displaycontro
